build.phonegap.com to generate signed APK

One of the development approach to create Android apps is using HTML5. By using this approach, the mobile app interface is designed using the HTML interface with the help of CSS and Javascript Framework called jqueryMobile. However, generating the APK file for this HTML web-based app is quite a hassle. Or should I say it’s difficult for novice apps developer. As the system’s environment variable need to be tweeked manually in order for the nodejs, npm client, JDK, Android SDK and several other tools to integrate to each other.

Thanks to build.phonegap.com , those tedious processes are no more.

STEP 1: Register for an ADOBE ID, at build.phonegap.com.


Choose the FREE plan this time. You could have one app to manage this time. As you have more projects, you may sign up for U$D9.99/month subscription fee. Or if you or your company already have Adobe Creative Cloud Membership, just use them.


Create an ADOBE ID if you don’t have one.


There you have your account and ready to upload a HTML project.


STEP 2: Preparing the HTML project.

I just would provide the finished product of our simple directory app (download here). If you’re familiar with HTML, and would like to modify the HTML project – please do so. After finishing the modification, archive the folder back to zip format.

The main code for index.html

<!DOCTYPE html>
<html>
<head><title>Kerul.net Company Directory</title>
<meta charset="utf-8">
<meta name="viewport" content="width=device-width, initial-scale=1">
<link href="css/jquery.mobile-1.4.5.min.css" rel="stylesheet" type="text/css" />
<script src="js/jquery-1.11.1.min.js"></script><script src="js/jquery.mobile-1.4.5.min.js"></script>
<link rel="stylesheet" href="css/themes/kerul-net.css" />
<link rel="stylesheet" href="css/themes/jquery.mobile.icons.min.css" />

</head>
<body>
<!-- main page -->
<div data-role="page" id="home">
<!-- header -->
<div data-role="header" data-position="fixed">
<h1>kerul.net</h1>
</div>

<!-- content -->
<div role="main" class="ui-content">
<p>This app provide info about the company.</p>
<img src="images/logo.jpg" width="200"
height="200">
</br>
</div><!-- end content -->

<!-- footer -->
<div data-role="footer" data-position="fixed">
<div data-role="navbar">
<ul>
<li><a href="#home" >Home</a></li>
<li><a href="#direktori" >Dir</a></li>
<li><a href="#about" >About</a></li>
</ul>
</div><!-- end navbar -->
</div><!-- end footer -->
</div><!-- end of home -->

<!-- about apps -->
<div data-role="page" id="about">
<!-- header -->
<div data-role="header" data-position="fixed">
<h1>Welcome to kerul.net</h1>
</div>

<!-- content -->
<div role="main" class="ui-content">
<p>Developer - kerul</p>
<a href="http://kerul.net" target="_blank"> go to kerul.net</a>
</br>
</div><!-- end content -->

<!-- footer -->
<div data-role="footer" data-position="fixed">
<div data-role="navbar">
<ul>
<li><a href="#home" >Home</a></li>
<li><a href="#direktori" >Dir</a></li>
<li><a href="#about" >About</a></li>
</ul>
</div><!-- end navbar -->
</div><!-- end footer -->
</div><!-- end of home -->

<!-- direktori page -->
<div data-role="page" id="direktori">
<!-- header -->
<div data-role="header" data-position="fixed">
<h1>Welcome to kerul.net</h1>
</div>

<!-- content -->
<div role="main" class="ui-content">
<p>Company staff directory</p>
<ul data-role="listview" data-filter="true" data-filter-reveal="true" data-filter-placeholder="Search staffs..." data-inset="true">
<li><a href="#s1" data-rel="popup">Khirulnizam</a></li>
<li><a href="#s2" data-rel="popup">Ashraf Chunawi</a></li>
<li><a href="#s3" data-rel="popup">Faiz Othman</a></li>
<li><a href="#s4" data-rel="popup">Athirah Ghani</a></li>
<li><a href="#s5" data-rel="popup">Najwa Humaira</a></li>
<li><a href="#s6" data-rel="popup">Osman Ahmad</a></li>
</ul>
</div><!-- end content -->

<!-- popup staff1 -->
<div id="s1" data-role="popup">
<ul data-role="listview" data-inset="true">
<li><a href="tel:+6012-9034614"
class="ui-icon-phone ui-btn
ui-btn-icon-left ui-btn-corner-all ui-btn-inline"
>
Call</a></li>
<li><a href="mailto:khirulnizam@gmail.com"
class="ui-icon-mail
ui-btn ui-btn-icon-left ui-btn-corner-all
ui-btn-inline"
>
Email</a></li>
</ul>
</div>
<!-- popup staff2 -->
<div id="s2" data-role="popup">
<ul data-role="listview" data-inset="true">
<li><a href="tel:+6012-0122655055"
class="ui-icon-phone ui-btn
ui-btn-icon-left ui-btn-corner-all ui-btn-inline"
>
Call</a></li>
<li><a href="mailto:mf4iz@gmail.com"
class="ui-icon-mail
ui-btn ui-btn-icon-left ui-btn-corner-all
ui-btn-inline"
>
Email</a></li>
</ul>
</div>

<!-- footer -->
<div data-role="footer" data-position="fixed">
<div data-role="navbar">
<ul>
<li><a href="#home" >Home</a></li>
<li><a href="#direktori" >Dir</a></li>
<li><a href="#about" >About</a></li>
</ul>
</div><!-- end navbar -->
</div><!-- end footer -->
</div><!-- end of direktori -->
</body>
</html>





Config.xml is the configuration file for phoneGap HTML project. Here it contains several information such as develeoper ID, version code, version number, developer profile, icon file, splash file, and so on.


The code for config.xml


<?xml version="1.0" encoding="UTF-8" ?>
<widget xmlns = "http://www.w3.org/ns/widgets"
xmlns:gap = "http://phonegap.com/ns/1.0"
id = "net.kerul.dir"
versionCode = "1"
version = "1.0.0" >
<!-- versionCode is optional and Android only -->
<name>Kerul.net Direktori App</name>
<description>
Direktori apps for KERUL.net
</description>
<author href="http://kerul.net" email="khirulnizam@gmail.com">
Khirulnizam Abd Rahman
</author>
<gap:splash src="splash.png" />
<icon src="icon.png" />
</widget>


Download here for the complete HTML project with the jquerymobile library.




 image Interface sample


STEP 3: Uploading the HTML project.




Use the button “upload a .zip file” available in the https://build.phonegap.com/apps and locate the zip file downloaded in the step 3.


Wait for a while for the progress bar disappear, and you’ll see the following page.




Should your HTML project has no error, click the button “Ready to Build”.




Build.phonegap.com currently support iOS, Android and Windows Phone.Read means you have some errors on iOS platform. Android and WinPhone are blue, means the build was successful and you may continue to test the .APK and .XAP in your device or emulator. Click on the arrow to see details.




Use any bar-code scanner to download the APK file to your Android device (eg: Barcode Scanner by ZXing Team).


STEP 4: Creating keystore file for ANDROID app


STEP 5: Uploading the keystore to our ANDROID project


STEP 6: Testing the app in our mobile device


STEP 7: Uploading the ANDROID app to the Google Play Store


This post is developing, thanks for your patient…
